Jobsite Series™ 4’ Basic mini

Model: I-IMCN UPC: 778300100200

Product specifications

Assembled dimensions
(W X D X H)

41 X 22.5 X 45.75 IN. (104.1 X 57.2 X 116.2 CM)

Package dimensions
(W X D X H)

43.25 X 24 X 4.5 in. (109.9 X 61 X 11.4 CM)

Weight

50 LB (22.7 KG)

Load capacity

500 LB (227 KG) Combined weight of user + materials. 250 lb (113 kg) per platform

Working heights

10 - 21.5 - 33 IN. (25 - 55 - 84 CM)

Reach

9 FT (2.75 M)

Finish

POWDER COATED

Platform

2 ANTI-SLIP. 14 GAUGE STEEL.

Structure

1 IN. (2.5 CM) OUTSIDE DIAMETER. 16 GAUGE STEEL

Casters

4 IN. (10 CM) DOUBLE LOCKING HEAVY DUTY

Standards

ANSI, CSA AND OSHA
Product links

Instructions manual

Sell-sheet

Replacement parts
FAQ
Can I use the rungs of the interior scaffolding to climb on the platform ?

For the 6' Baker (I-CISC, I-BMSS, I-CAISC) & 6' (I-IRC, I-BM6S) scaffoldings, yes you have to use the rungs of the frame. If the scaffolding has a platform with trapdoor, you have to climb from the inside of the scaffold. If the platform does not have a trapdoor, climb from the outside of the scaffold while respecting the “Maximum climbing distance” table in the assembly instruction. You can find the assembly instruction on our website under the product’s heading.

For the 6' (I-CAIRC), 5' (I-IMIS) and 4' (I-IMCN, I-BM4S, I-IMAC) scaffoldings, no you cannot use the rungs to climb up or down the structure. You have to use the platforms.

Are the Jobsite Series 6′ (I-IRC), 5′ (I-IMIS) and 4′ (I-IMCN) all stackable?

The Jobsite Series 6' (I-IRC) is stackable. It can be stacked 2 units high, one on top of the other. When stacking two units, guardrail (I-IRGR) and outriggers (I-IRO4) must be installed.

The Jobsite Series 5' (I-IMIS) & 4' (I-IMCN) are not stackable. Use only one unit high.

Do you have an interior scaffolding that has a higher capacity than the Jobsite Series scaffoldings?

Yes, the Buildman Grade has a higher capacity than the Jobsite Series.

Do you have a lighter interior scaffolding than the Jobsite Series scaffoldings?

Yes, the Alu Series, made of aluminum, is lighter than the Jobsite Series which is made of steel.

Are there casters with a larger diameter available for the mobile scaffolding 4′ Jobsite Serie (I-IMCN)?

No, the mobile scaffoldings 4' Jobsite Series only come with 4" diameter casters.
